The Puretec IL-TM10 is a compact inline undersink drinking-water filtration system supplied with a chrome TM10 three-way mixer tap. The three-way design combines normal hot water, normal cold water and filtered drinking water within one kitchen tap.
The IL-TM10 uses premium-grade KDF media with a nominal 1-micron filtration rating to help reduce chlorine, sediment, bad taste, odour and heavy metals from the filtered drinking-water supply.
Its slimline filter can be mounted horizontally or vertically beneath the kitchen bench. Puretec lists a filtered-water flow rate of up to 1.9 litres per minute and a cartridge treatment capacity of up to 9,500 litres.
Important: Puretec currently lists the IL-TM10 as discontinued. Availability therefore depends on remaining stock and should be confirmed before ordering.
The IL-TM10 filters the drinking-water supply underneath the kitchen bench before directing that filtered water to the dedicated filtered-water pathway in the TM10 three-way mixer tap.
The system is designed to help reduce chlorine, sediment, heavy metals, bad taste and odour from drinking water.
Because the filtered-water pathway is incorporated into the three-way mixer, the kitchen does not require a separate small drinking-water faucet beside the main tap.
The slimline undersink filter and combined three-way mixer can suit kitchens where available under-bench and sink-area space is limited.
The IL-TM10 provides point-of-use filtration for drinking and food-preparation water rather than filtering the entire household water supply.
The TM10 provides hot, cold and filtered water through one fixture, avoiding the visual clutter of a separate drinking-water tap.
Puretec specifies the IL-TM10 for reducing chlorine together with unwanted taste and odour in drinking water.
The inline filtration media is also specified for reducing sediment and heavy metals from the filtered-water supply.
The supplied three-way mixer incorporates the filtered-water outlet into the main kitchen tap rather than requiring an additional faucet.
You want compact undersink drinking-water filtration and prefer filtered, hot and cold water to be delivered through one kitchen tap.
You require whole-house filtration, reverse osmosis, UV disinfection, dedicated microbiological treatment or a current Puretec model with ongoing manufacturer availability.
Confirm remaining stock, existing tap-hole suitability, under-sink space, incoming pressure and access to the kitchen cold-water plumbing.
Puretec states that the IL-TM10 uses premium-grade KDF media and is designed to help reduce:
Puretec does not specify the IL-TM10 as a reverse-osmosis or UV disinfection system. It should not be promoted as providing microbiological sterilisation of untreated water.
The IL-TM10 uses premium-grade KDF filtration media in a compact inline cartridge.
Puretec specifies this media configuration for reducing chlorine, sediment, bad taste, odour and heavy metals while providing a compact point-of-use drinking-water filtration solution.
The replacement cartridge used across Puretec's IL-TM inline systems is the IN149C, a 1-micron KDF/carbon inline cartridge with a 1/4-inch quick-connect fitting.
The supplied TM10 three-way mixer tap combines three separate kitchen-water functions in one fixture.
Normal household hot water continues through the standard mixer function.
Normal unfiltered cold water remains available for routine kitchen use.
The IL-TM10 supplies filtered drinking water through the dedicated filtered-water pathway within the mixer tap.
Puretec lists a nominal filtration rating of 1 micron for the IL-TM10.
The inline filtration media is designed for chlorine, sediment, taste, odour and heavy-metal reduction.
The included mixer combines hot, cold and filtered drinking water into a single kitchen tap.
Puretec's IL-TM10 specification sheet lists a cartridge treatment capacity of up to 9,500 litres.
The slimline filter can be installed in either orientation to suit the available under-sink space.
Puretec states that the plumbing fittings required for a standard installation are supplied with the system.
| Specification | Details |
|---|---|
| Brand | Puretec |
| Model | IL-TM10 |
| Product Type | Inline undersink drinking-water filter with 3-way mixer tap |
| Current Manufacturer Status | Discontinued |
| Tap Style | 3-way mixer tap |
| Tap Model | TM10 |
| Replacement Cartridge | IN149C |
| Filter Media | KDF / carbon |
| Filtered Water Flow Rate | 0–1.9 L/min |
| Nominal Micron Rating | 1 micron |
| Cartridge Capacity | Up to 9,500 litres |
| Operating Temperature | 0–38°C; protect from freezing |
| Maximum Pressure | 500 kPa* |
| Filtered-Water Connection | 1/4" Quick Connect |
| Filter Size | Approximately 65 mm diameter x 270 mm high |
| Mounting | Horizontal or vertical |
| Warranty | 1 year parts and labour, excluding cartridges and subject to current Puretec warranty conditions |
*Puretec states that where line pressure exceeds 500 kPa, an approved pressure-limiting device must be installed in accordance with applicable Australian and New Zealand plumbing standards.
The IL-TM10 installs beneath the kitchen bench with the filter connected to the dedicated filtered-water pathway of the TM10 three-way mixer tap.
Puretec describes the IL-TM10 as easy to install and supplies plumbing fittings for a standard installation. The finished installation should still meet applicable plumbing requirements.
Puretec's current IL-TM10 product page lists a maximum pressure of 500 kPa.
Where line pressure exceeds this level, Puretec requires an approved pressure-limiting device to protect the system and comply with applicable Australian and New Zealand plumbing requirements.
The current manufacturer-listed filtered-water flow range is 0–1.9 L/min. The earlier 1.9–2.8 L/min claim should not be used for this model.
Puretec describes the IL-TM10 as ideal for town and rural water supplies.
That does not mean the IL-TM10 should be treated as a complete purification system for untreated rainwater, bore water or another microbiologically unsafe source. The product does not include UV sterilisation or another dedicated disinfection stage.
Puretec's IL-TM10 specification sheet lists a treatment capacity of up to 9,500 litres.
Actual cartridge life depends on incoming water quality, sediment levels, chlorine concentration and the amount of filtered drinking water used.
A reduction in filtered-water flow or the return of unwanted taste or odour can indicate that cartridge replacement is required before the maximum treatment capacity is reached.
The IL-TM10 uses a replaceable inline cartridge. Puretec describes the replacement cartridge as a do-it-yourself cartridge, allowing routine filter changes without replacing the tap or entire filtration system.
The genuine Puretec IN149C cartridge is specified for the IL-TM Series and uses a 1/4-inch quick-connect fitting.
IN149C
1-micron KDF/carbon inline cartridge with 1/4-inch quick-connect fitting.
Replace according to service life and water conditions, or earlier where reduced flow or a noticeable change in taste or odour indicates declining filter performance.
The compact undersink inline filtration system with 1-micron KDF filtration.
The supplied kitchen mixer provides normal hot and cold water plus a dedicated filtered drinking-water pathway.
Puretec states that the system includes the plumbing fittings required for a standard installation.
Puretec currently lists the IL-TM10 as discontinued.
That means new supply depends on remaining stock rather than ongoing manufacturer production. Availability should be confirmed before accepting an order.
Where no IL-TM10 stock remains, a current Puretec three-way mixer and undersink filtration package should be considered instead.
Where remaining stock is available, choose supply only if you already have the required installation arrangements in place.
If stock remains available, eligible Brisbane customers can check supplied-and-installed options and kitchen suitability.
If stock remains available, eligible Gold Coast customers can check installation availability and site requirements.
Because Puretec has discontinued the IL-TM10, Australia-wide supply depends on remaining stock. Where stock is available, Installed Today may be able to supply supported Australian locations.
A three-way mixer combines normal kitchen hot water, normal cold water and filtered drinking water within one fixture.
This removes the need for a separate drinking-water faucet and can create a cleaner, less cluttered sink area.
With the IL-TM10, Puretec combines the TM10 mixer with a slimline inline filter beneath the kitchen bench.
Yes. Puretec currently lists the IL-TM10 as discontinued. New supply depends on remaining stock.
Puretec specifies the IL-TM10 for reducing chlorine, sediment, heavy metals, bad taste and odour.
The manufacturer lists a nominal 1-micron filtration rating.
Yes. Puretec states that the IL-TM Series uses premium-grade KDF media.
The Puretec IN149C cartridge is specified for the IL-TM Series.
Puretec's IL-TM10 specification lists a capacity of up to 9,500 litres.
The current Puretec product page lists a range of 0–1.9 L/min.
Yes. The system includes the TM10 three-way mixer tap.
It supplies normal hot water, normal cold water and filtered drinking water through one kitchen fixture.
No. The filtered-water pathway is incorporated into the TM10 mixer.
No. It is an inline KDF filtration system rather than a reverse-osmosis system.
No. UV disinfection is not part of the IL-TM10.
Puretec does not specify the IL-TM10 as a microbiological purification system. It should not be promoted as a stand-alone bacteria-removal filter.
Puretec does not list dedicated scale-prevention or water-softening technology as part of the IL-TM10.
Yes. Puretec states that it can be mounted horizontally or vertically.
Puretec currently lists 500 kPa. Where incoming pressure exceeds this level, an approved pressure-limiting device is required.
The operating temperature range is 0–38°C, and the system must be protected from freezing.
The filtered-water circuit uses a 1/4-inch quick-connect connection.
Yes. Puretec specifically describes the replacement cartridge as a do-it-yourself cartridge.
Puretec describes the product as easy to install and supplies standard plumbing fittings, but the finished installation still needs to comply with applicable plumbing requirements.
Puretec describes the IL-TM10 as suitable for town and rural water supplies but does not specify it as a complete microbiological rainwater-treatment system. Untreated rainwater may require additional filtration and disinfection.
Puretec lists a 1-year parts-and-labour warranty, excluding cartridges and subject to current warranty conditions.
Puretec lists a 1-year parts-and-labour warranty for the IL-TM10. Filter cartridges are excluded and coverage remains subject to the current manufacturer warranty terms.
The system should be protected from freezing and operated within the manufacturer's pressure and temperature limits.
Puretec specifies the genuine IN149C replacement cartridge for the IL-TM Series. Actual cartridge life depends on the amount of filtered water used and the quality of the incoming water.
The Puretec IL-TM10 is primarily suited to kitchens wanting compact point-of-use drinking-water filtration together with a single three-way mixer tap. Its key characteristics are its 1-micron KDF filtration, filtered-water flow of up to 1.9 L/min, up to 9,500 litres of cartridge capacity and ability to deliver filtered, hot and cold water from one kitchen fixture.
It should not be confused with a reverse-osmosis, UV purification, dedicated scale-treatment or stand-alone microbiological water-treatment system.
Puretec currently lists the IL-TM10 as discontinued, so confirm remaining stock before ordering. Where no stock remains, consider a current Puretec three-way mixer and undersink filtration package.
